SMARTLINE® ST700 flush-mounted flange transmitter

As a member of the SmartLine® product series, the STG73P is an embedded-mounted diaphragm pressure transmitter. The sleeve is welded onto the process pipeline, and the embedded transmitter's diaphragm surface is flush with the process pipe wall. Because embedded installation avoids the occurrence of blockages, it is commonly used on the headbox of pulp and paper mills, allowing for quick and convenient installation or replacement.

● The accuracy of the verification range is up to 0.065%, with 0.04% being optional

● Stability: 0.02% of full scale, maintained for 10 years

● Automatic temperature compensation

● Measurement range ratio of 100:1

● Response time is as fast as 100ms

● Easy to use and intuitive display function

● External zero position, range, and configuration functions

● Perfect self-diagnostic function

● Based on ANSI/NFPA 70-202 and ANSI/ISA 12.27.0, it integrates a dual sealing design to ensure safety

● The standard configuration fully meets SIL2/3 requirements.
